Chain drive parameters of the NE series whole machine

Model	Number Of Poles	Gear Reduction Ratio	Number Of Teeth		Chain Transmission	Chain Speed	SD Type Bucket Elevator Capacity	S Type Bucket Elevator Capacity
Model	Number Of Poles	Gear Reduction Ratio	z1	z2	Chain Transmission	Chain Speed	SD Type Bucket Elevator Capacity	S Type Bucket Elevator Capacity
NE15	4	31.5	17	40	20A	30	13.5	/
NE15	6	20	17	40	20A	30	13.5	/
NE30	4	25	17	53	24A	33	27	/
NE30	6	16	17	53	24A	33	27	/
NE50	4	25	17	53	24A	33	55	69
NE50	6	16	17	53	24A	33	55	69
NE100	4	31.5	17	50	24A	33.5	100	124
NE100	6	20	17	50	28A	33.5	100	124
NE150	4	31.5	17	50	24A	33.5	150	187
NE150	6	20	17	50	28A	33.5	150	187
NE200	4	31.5	19	73	28A	32.1	185	235
NE200	6	20	19	73	28A	32.1	185	235
NE300	4	31.5	19	73	28A	32.1	278	355
NE300	6	20	19	73	28A	32.1	278	355
NE400	4	40	19	69	32A	35.1	365	460
NE400	6	25	19	69	40A	35.1	365	460
